| Working range (XxZ) [mm] |
720 x 250 (28,35'' x 9,84'') |
| Working range (Y) [mm] |
±15 (0,59'') (optional) |
| Diameter of cylinder [mm] |
40 - 320 (1,57'' - 12,6'') |
| Body length. max. [mm] |
720 |
| Journal diameter max. [mm] |
100 |
| Feed rate (X/Z) [m/min] |
30 |
| Feed rate (Y) [m/min] |
15 |
| Feed rate (A) [min-1] |
100 |
| Max. acceleration [m/s²] |
10 |
| Spindle speed [rpm] |
5.000 - 60.000 |
| Spindle power [kW] |
1,2-10 |
| Load capacity [kg] |
400 (depends on the used round axis) |
| Dimensions (LxBxH) [mm] |
2.800 x 3.400 x 850 |
| Weight of machine [kg] |
8.000 (RM 800S) |
| Weight of machine [kg] |
8.500 (RM 800S/Y) |
| Controller |
andronic2060 |
| Output software |
LDriver |
| |
|
| Options |
|
| |
Different spindle types |
| |
Chain-type tool charger for up to 50 tools |
| |
Disk-type tool charger for up to 45 tools |
| |
PC measuring optic, inspection camera systems |
| |
Laser tool measurement Blum |
| |
Edge probe OMP 40 |
| |
LANG Software package CAD & Design |
