| Dimensions (W/D/H) [mm] |
1.560/1.800/2.300 |
|
|
| Weight of machine [kg] |
2.000 |
|
|
| Working range (X/Y/Z) [mm] |
300/300/300 (referring to middle of work piece and focus) |
|
|
| Max. load capacity (work piece and accessories) [kg] |
100 |
|
|
| Measuring system |
Glass scales |
|
|
| Controller |
LNC compact |
|
|
| Output software |
LDriver |
|
|
| |
|
|
|
| Standard laser unit |
|
|
|
| Laser medium |
Fiber laser |
|
|
| Wavelength [nm] |
1064 |
|
|
| Power in ground mode (TEM00) [W] |
20 |
50 |
|
| Cooling system |
Air cooled |
|
|
| Pulse repetition rate [kHz] |
25 - 1000 |
25 - 1000 |
|
| |
|
|
|
| Objective |
|
|
|
| F-Theta objective [mm] |
80 |
100 |
150 |
| Max. scan field [mm] |
45 x 45 |
54 x 54 |
110 x 110 |
| Smallest spot size [µm] |
23 |
30 |
47 |
| Special features/options |
F-Theta telecentric objective |
F-Theta telecentric objective |
F-Theta objective; not telecentric |
